AVIFileSink Class Reference

#include <AVIFileSink.hh>

Inheritance diagram for AVIFileSink:

[legend]Collaboration diagram for AVIFileSink:


Public Types
typedef void(	afterPlayingFunc )(void *clientData)
Public Member Functions
Boolean	startPlaying (afterPlayingFunc afterFunc, void afterClientData)
unsigned	numActiveSubsessions () const
UsageEnvironment &	envir () const
char const *	name () const
virtual Boolean	isSource () const
virtual Boolean	isSink () const
virtual Boolean	isRTCPInstance () const
virtual Boolean	isRTSPClient () const
virtual Boolean	isRTSPServer () const
virtual Boolean	isMediaSession () const
virtual Boolean	isServerMediaSession () const
virtual Boolean	isDarwinInjector () const
Static Public Member Functions
static AVIFileSink *	createNew (UsageEnvironment &env, MediaSession &inputSession, char const *outputFileName, unsigned bufferSize=20000, unsigned short movieWidth=240, unsigned short movieHeight=180, unsigned movieFPS=15, Boolean packetLossCompensate=False)
static Boolean	lookupByName (UsageEnvironment &env, char const mediumName, Medium &resultMedium)
static void	close (UsageEnvironment &env, char const *mediumName)
static void	close (Medium *medium)
Protected Member Functions
TaskToken &	nextTask ()
Private Member Functions
	AVIFileSink (UsageEnvironment &env, MediaSession &inputSession, FILE *outFid, unsigned bufferSize, unsigned short movieWidth, unsigned short movieHeight, unsigned movieFPS, Boolean packetLossCompensate)
virtual	~AVIFileSink ()
Boolean	continuePlaying ()
void	onSourceClosure1 ()
void	completeOutputFile ()
unsigned	addWord (unsigned word)
unsigned	addHalfWord (unsigned short halfWord)
unsigned	addByte (unsigned char byte)
unsigned	addZeroWords (unsigned numWords)
unsigned	add4ByteString (char const *str)
void	setWord (unsigned filePosn, unsigned size)
	_header (AVI)
	_header (hdrl)
	_header (avih)
	_header (strl)
	_header (strh)
	_header (strf)
	_header (JUNK)
	_header (movi)
Static Private Member Functions
static void	afterGettingFrame (void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds)
static void	onSourceClosure (void *clientData)
static void	onRTCPBye (void *clientData)
Private Attributes
MediaSession &	fInputSession
FILE *	fOutFid
unsigned	fBufferSize
Boolean	fPacketLossCompensate
Boolean	fAreCurrentlyBeingPlayed
afterPlayingFunc *	fAfterFunc
void *	fAfterClientData
unsigned	fNumSubsessions
unsigned	fNumBytesWritten
timeval	fStartTime
Boolean	fHaveCompletedOutputFile
unsigned short	fMovieWidth
unsigned short	fMovieHeight
unsigned	fMovieFPS
unsigned	fRIFFSizePosition
unsigned	fRIFFSizeValue
unsigned	fAVIHMaxBytesPerSecondPosition
unsigned	fAVIHFrameCountPosition
unsigned	fMoviSizePosition
unsigned	fMoviSizeValue
AVISubsessionIOState *	fCurrentIOState
unsigned	fJunkNumber
Friends
class	AVISubsessionIOState

Detailed Description

Definition at line 28 of file AVIFileSink.hh.

Member Typedef Documentation

typedef void( AVIFileSink::afterPlayingFunc)(void *clientData)

Definition at line 39 of file AVIFileSink.hh.

Constructor & Destructor Documentation

AVIFileSink::AVIFileSink	(	UsageEnvironment &	env,
		MediaSession &	inputSession,
		FILE *	outFid,
		unsigned	bufferSize,
		unsigned short	movieWidth,
		unsigned short	movieHeight,
		unsigned	movieFPS,
		Boolean	packetLossCompensate
	)			`[private]`

Definition at line 99 of file AVIFileSink.cpp.

References AVISubsessionIOState, fInputSession, fMovieFPS, fMovieHeight, fMovieWidth, fNumSubsessions, iter, MediaSubsession::miscPtr, MediaSubsessionIterator::next(), NULL, onRTCPBye(), MediaSubsession::readSource(), MediaSubsession::rtcpInstance(), RTCPInstance::setByeHandler(), subsession, MediaSubsession::videoFPS(), MediaSubsession::videoHeight(), and MediaSubsession::videoWidth().

Referenced by createNew().

00105   : Medium(env), fInputSession(inputSession), fOutFid(outFid),
00106     fBufferSize(bufferSize), fPacketLossCompensate(packetLossCompensate),
00107     fAreCurrentlyBeingPlayed(False), fNumSubsessions(0), fNumBytesWritten(0),
00108     fHaveCompletedOutputFile(False),
00109     fMovieWidth(movieWidth), fMovieHeight(movieHeight), fMovieFPS(movieFPS) {
00110   // Set up I/O state for each input subsession:
00111   MediaSubsessionIterator iter(fInputSession);
00112   MediaSubsession* subsession;
00113   while ((subsession = iter.next()) != NULL) {
00114     // Ignore subsessions without a data source:
00115     FramedSource* subsessionSource = subsession->readSource();
00116     if (subsessionSource == NULL) continue;
00117
00118     // If "subsession's" SDP description specified screen dimension
00119     // or frame rate parameters, then use these.
00120     if (subsession->videoWidth() != 0) {
00121       fMovieWidth = subsession->videoWidth();
00122     }
00123     if (subsession->videoHeight() != 0) {
00124       fMovieHeight = subsession->videoHeight();
00125     }
00126     if (subsession->videoFPS() != 0) {
00127       fMovieFPS = subsession->videoFPS();
00128     }
00129
00130     AVISubsessionIOState* ioState
00131       = new AVISubsessionIOState(*this, *subsession);
00132     subsession->miscPtr = (void*)ioState;
00133
00134     // Also set a 'BYE' handler for this subsession's RTCP instance:
00135     if (subsession->rtcpInstance() != NULL) {
00136       subsession->rtcpInstance()->setByeHandler(onRTCPBye, ioState);
00137     }
00138
00139     ++fNumSubsessions;
00140   }
00141
00142   // Begin by writing an AVI header:
00143   addFileHeader_AVI();
00144 }

AVIFileSink::~AVIFileSink ( ) [private, virtual]

Definition at line 146 of file AVIFileSink.cpp.

References completeOutputFile(), fInputSession, iter, MediaSubsession::miscPtr, MediaSubsessionIterator::next(), NULL, and subsession.

00146                           {
00147   completeOutputFile();
00148
00149   // Then, delete each active "AVISubsessionIOState":
00150   MediaSubsessionIterator iter(fInputSession);
00151   MediaSubsession* subsession;
00152   while ((subsession = iter.next()) != NULL) {
00153     AVISubsessionIOState* ioState
00154       = (AVISubsessionIOState*)(subsession->miscPtr);
00155     if (ioState == NULL) continue;
00156
00157     delete ioState;
00158   }
00159 }

Member Function Documentation

AVIFileSink * AVIFileSink::createNew	(	UsageEnvironment &	env,
		MediaSession &	inputSession,
		char const *	outputFileName,
		unsigned	bufferSize = `20000`,
		unsigned short	movieWidth = `240`,
		unsigned short	movieHeight = `180`,
		unsigned	movieFPS = `15`,
		Boolean	packetLossCompensate = `False`
	)			`[static]`

Definition at line 162 of file AVIFileSink.cpp.

References AVIFileSink(), env, NULL, and OpenOutputFile().

Referenced by main().

00166                                                              {
00167   do {
00168     FILE* fid = OpenOutputFile(env, outputFileName);
00169     if (fid == NULL) break;
00170
00171     return new AVIFileSink(env, inputSession, fid, bufferSize,
00172                            movieWidth, movieHeight, movieFPS,
00173                            packetLossCompensate);
00174   } while (0);
00175
00176   return NULL;
00177 }

Boolean AVIFileSink::startPlaying	(	afterPlayingFunc *	afterFunc,
		void *	afterClientData
	)

Definition at line 179 of file AVIFileSink.cpp.

References continuePlaying(), Medium::envir(), fAfterClientData, fAfterFunc, False, fAreCurrentlyBeingPlayed, UsageEnvironment::setResultMsg(), and True.

Referenced by main().

00180                                                          {
00181   // Make sure we're not already being played:
00182   if (fAreCurrentlyBeingPlayed) {
00183     envir().setResultMsg("This sink has already been played");
00184     return False;
00185   }
00186
00187   fAreCurrentlyBeingPlayed = True;
00188   fAfterFunc = afterFunc;
00189   fAfterClientData = afterClientData;
00190
00191   return continuePlaying();
00192 }

unsigned AVIFileSink::numActiveSubsessions ( ) const [inline]

Definition at line 43 of file AVIFileSink.hh.

References fNumSubsessions.

Referenced by checkForPacketArrival().

00043 { return fNumSubsessions; }

Boolean AVIFileSink::continuePlaying ( ) [private]

Definition at line 194 of file AVIFileSink.cpp.

References afterGettingFrame(), SubsessionBuffer::bytesAvailable(), SubsessionBuffer::dataEnd(), Medium::envir(), False, AVISubsessionIOState::fBuffer, fInputSession, FramedSource::getNextFrame(), FramedSource::isCurrentlyAwaitingData(), iter, MediaSubsession::miscPtr, MediaSubsessionIterator::next(), NULL, onSourceClosure(), MediaSubsession::readSource(), UsageEnvironment::setResultMsg(), subsession, and True.

Referenced by AVISubsessionIOState::afterGettingFrame(), and startPlaying().

00194                                      {
00195   // Run through each of our input session's 'subsessions',
00196   // asking for a frame from each one:
00197   Boolean haveActiveSubsessions = False;
00198   MediaSubsessionIterator iter(fInputSession);
00199   MediaSubsession* subsession;
00200   while ((subsession = iter.next()) != NULL) {
00201     FramedSource* subsessionSource = subsession->readSource();
00202     if (subsessionSource == NULL) continue;
00203
00204     if (subsessionSource->isCurrentlyAwaitingData()) continue;
00205
00206     AVISubsessionIOState* ioState
00207       = (AVISubsessionIOState*)(subsession->miscPtr);
00208     if (ioState == NULL) continue;
00209
00210     haveActiveSubsessions = True;
00211     unsigned char* toPtr = ioState->fBuffer->dataEnd();
00212     unsigned toSize = ioState->fBuffer->bytesAvailable();
00213     subsessionSource->getNextFrame(toPtr, toSize,
00214                                    afterGettingFrame, ioState,
00215                                    onSourceClosure, ioState);
00216   }
00217   if (!haveActiveSubsessions) {
00218     envir().setResultMsg("No subsessions are currently active");
00219     return False;
00220   }
00221
00222   return True;
00223 }

void AVIFileSink::afterGettingFrame	(	void *	clientData,
		unsigned	frameSize,
		unsigned	numTruncatedBytes,
		struct timeval	presentationTime,
		unsigned	durationInMicroseconds
	)			`[static, private]`

Definition at line 226 of file AVIFileSink.cpp.

References AVISubsessionIOState::afterGettingFrame().

Referenced by continuePlaying().

00229                                                          {
00230   AVISubsessionIOState* ioState = (AVISubsessionIOState*)clientData;
00231   ioState->afterGettingFrame(packetDataSize, presentationTime);
00232 }

void AVIFileSink::onSourceClosure ( void * clientData ) [static, private]

Definition at line 234 of file AVIFileSink.cpp.

References AVISubsessionIOState::onSourceClosure().

Referenced by continuePlaying().

00234                                                   {
00235   AVISubsessionIOState* ioState = (AVISubsessionIOState*)clientData;
00236   ioState->onSourceClosure();
00237 }

void AVIFileSink::onSourceClosure1 ( ) [private]

Definition at line 239 of file AVIFileSink.cpp.

References completeOutputFile(), fAfterClientData, fAfterFunc, fInputSession, AVISubsessionIOState::fOurSourceIsActive, iter, MediaSubsession::miscPtr, MediaSubsessionIterator::next(), NULL, and subsession.

Referenced by AVISubsessionIOState::onSourceClosure().

00239                                    {
00240   // Check whether *all* of the subsession sources have closed.
00241   // If not, do nothing for now:
00242   MediaSubsessionIterator iter(fInputSession);
00243   MediaSubsession* subsession;
00244   while ((subsession = iter.next()) != NULL) {
00245     AVISubsessionIOState* ioState
00246       = (AVISubsessionIOState*)(subsession->miscPtr);
00247     if (ioState == NULL) continue;
00248
00249     if (ioState->fOurSourceIsActive) return; // this source hasn't closed
00250   }
00251
00252   completeOutputFile();
00253
00254   // Call our specified 'after' function:
00255   if (fAfterFunc != NULL) {
00256     (*fAfterFunc)(fAfterClientData);
00257   }
00258 }

void AVIFileSink::onRTCPBye ( void * clientData ) [static, private]

Definition at line 260 of file AVIFileSink.cpp.

References MediaSubsession::codecName(), AVISubsessionIOState::envir(), AVISubsessionIOState::fOurSink, AVISubsessionIOState::fOurSubsession, fStartTime, MediaSubsession::mediumName(), NULL, AVISubsessionIOState::onSourceClosure(), and subsession.

Referenced by AVIFileSink().

00260                                             {
00261   AVISubsessionIOState* ioState = (AVISubsessionIOState*)clientData;
00262
00263   struct timeval timeNow;
00264   gettimeofday(&timeNow, NULL);
00265   unsigned secsDiff
00266     = timeNow.tv_sec - ioState->fOurSink.fStartTime.tv_sec;
00267
00268   MediaSubsession& subsession = ioState->fOurSubsession;
00269   ioState->envir() << "Received RTCP \"BYE\" on \""
00270                    << subsession.mediumName()
00271                    << "/" << subsession.codecName()
00272                    << "\" subsession (after "
00273                    << secsDiff << " seconds)\n";
00274
00275   // Handle the reception of a RTCP "BYE" as if the source had closed:
00276   ioState->onSourceClosure();
00277 }

void AVIFileSink::completeOutputFile ( ) [private]

Definition at line 279 of file AVIFileSink.cpp.

References fAVIHFrameCountPosition, fAVIHMaxBytesPerSecondPosition, fHaveCompletedOutputFile, fInputSession, AVISubsessionIOState::fIsAudio, AVISubsessionIOState::fIsVideo, AVISubsessionIOState::fMaxBytesPerSecond, fMoviSizePosition, fMoviSizeValue, fNumBytesWritten, AVISubsessionIOState::fNumFrames, fOutFid, fRIFFSizePosition, fRIFFSizeValue, AVISubsessionIOState::fSTRHFrameCountPosition, iter, MediaSubsession::miscPtr, MediaSubsessionIterator::next(), NULL, setWord(), subsession, and True.

Referenced by onSourceClosure1(), and ~AVIFileSink().

00279                                      {
00280   if (fHaveCompletedOutputFile || fOutFid == NULL) return;
00281
00282   // Update various AVI 'size' fields to take account of the codec data that
00283   // we've now written to the file:
00284   unsigned maxBytesPerSecond = 0;
00285   unsigned numVideoFrames = 0;
00286   unsigned numAudioFrames = 0;
00287
00289   MediaSubsessionIterator iter(fInputSession);
00290   MediaSubsession* subsession;
00291   while ((subsession = iter.next()) != NULL) {
00292     AVISubsessionIOState* ioState
00293       = (AVISubsessionIOState*)(subsession->miscPtr);
00294     if (ioState == NULL) continue;
00295
00296     maxBytesPerSecond += ioState->fMaxBytesPerSecond;
00297
00298     setWord(ioState->fSTRHFrameCountPosition, ioState->fNumFrames);
00299     if (ioState->fIsVideo) numVideoFrames = ioState->fNumFrames;
00300     else if (ioState->fIsAudio) numAudioFrames = ioState->fNumFrames;
00301   }
00302
00304   fRIFFSizeValue += fNumBytesWritten;
00305   setWord(fRIFFSizePosition, fRIFFSizeValue);
00306
00307   setWord(fAVIHMaxBytesPerSecondPosition, maxBytesPerSecond);
00308   setWord(fAVIHFrameCountPosition,
00309           numVideoFrames > 0 ? numVideoFrames : numAudioFrames);
00310
00311   fMoviSizeValue += fNumBytesWritten;
00312   setWord(fMoviSizePosition, fMoviSizeValue);
00313
00314   // We're done:
00315   fHaveCompletedOutputFile = True;
00316 }

unsigned AVIFileSink::addWord ( unsigned word ) [private]

Definition at line 486 of file AVIFileSink.cpp.

References addByte().

Referenced by addZeroWords(), if(), setWord(), and AVISubsessionIOState::useFrame().

00486                                            {
00487   // Add "word" to the file in little-endian order:
00488   addByte(word); addByte(word>>8);
00489   addByte(word>>16); addByte(word>>24);
00490
00491   return 4;
00492 }

unsigned AVIFileSink::addHalfWord ( unsigned short halfWord ) [private]

Definition at line 494 of file AVIFileSink.cpp.

References addByte().

Referenced by if().

00494                                                          {
00495   // Add "halfWord" to the file in little-endian order:
00496   addByte((unsigned char)halfWord); addByte((unsigned char)(halfWord>>8));
00497
00498   return 2;
00499 }

unsigned AVIFileSink::addByte ( unsigned char byte ) [inline, private]

Definition at line 82 of file AVIFileSink.hh.

References fOutFid.

Referenced by add4ByteString(), addHalfWord(), addWord(), and AVISubsessionIOState::useFrame().

00082                                        {
00083     putc(byte, fOutFid);
00084     return 1;
00085   }

unsigned AVIFileSink::addZeroWords ( unsigned numWords ) [private]

Definition at line 501 of file AVIFileSink.cpp.

References addWord().

Referenced by if().

00501                                                     {
00502   for (unsigned i = 0; i < numWords; ++i) {
00503     addWord(0);
00504   }
00505
00506   return numWords*4;
00507 }

unsigned AVIFileSink::add4ByteString ( char const * str ) [private]

Definition at line 509 of file AVIFileSink.cpp.

References addByte().

00509                                                     {
00510   addByte(str[0]); addByte(str[1]); addByte(str[2]);
00511   addByte(str[3] == '\0' ? ' ' : str[3]); // e.g., for "AVI "
00512
00513   return 4;
00514 }

void AVIFileSink::setWord	(	unsigned	filePosn,
		unsigned	size
	)			`[private]`

Definition at line 516 of file AVIFileSink.cpp.

References addWord(), Medium::envir(), fOutFid, and UsageEnvironment::getErrno().

Referenced by completeOutputFile().

00516                                                           {
00517   do {
00518     if (fseek(fOutFid, filePosn, SEEK_SET) < 0) break;
00519     addWord(size);
00520     if (fseek(fOutFid, 0, SEEK_END) < 0) break; // go back to where we were
00521
00522     return;
00523   } while (0);
00524
00525   // One of the fseek()s failed, probable because we're not a seekable file
00526   envir() << "AVIFileSink::setWord(): fseek failed (err "
00527           << envir().getErrno() << ")\n";
00528 }

AVIFileSink::_header ( AVI ) [private]

AVIFileSink::_header ( hdrl ) [private]

AVIFileSink::_header ( avih ) [private]

AVIFileSink::_header ( strl ) [private]

AVIFileSink::_header ( strh ) [private]

AVIFileSink::_header ( strf ) [private]

AVIFileSink::_header ( JUNK ) [private]

AVIFileSink::_header ( movi ) [private]

Boolean Medium::lookupByName	(	UsageEnvironment &	env,
		char const *	mediumName,
		Medium *&	resultMedium
	)			`[static, inherited]`

Definition at line 65 of file Media.cpp.

References env, False, MediaLookupTable::lookup(), NULL, MediaLookupTable::ourMedia(), UsageEnvironment::setResultMsg(), and True.

Referenced by ServerMediaSession::lookupByName(), RTSPServer::lookupByName(), RTSPClient::lookupByName(), RTCPInstance::lookupByName(), MediaSource::lookupByName(), MediaSink::lookupByName(), MediaSession::lookupByName(), and DarwinInjector::lookupByName().

00066                                                          {
00067   resultMedium = MediaLookupTable::ourMedia(env)->lookup(mediumName);
00068   if (resultMedium == NULL) {
00069     env.setResultMsg("Medium ", mediumName, " does not exist");
00070     return False;
00071   }
00072
00073   return True;
00074 }

void Medium::close	(	UsageEnvironment &	env,
		char const *	mediumName
	)			`[static, inherited]`

Definition at line 76 of file Media.cpp.

References env, MediaLookupTable::ourMedia(), and MediaLookupTable::remove().

Referenced by afterPlaying(), Medium::close(), closeMediaSinks(), OnDemandServerMediaSubsession::closeStreamSource(), WAVAudioFileSource::createNew(), QCELPAudioRTPSource::createNew(), MP3HTTPSource::createNew(), MP3FileSource::createNew(), AMRAudioRTPSource::createNew(), WAVAudioFileServerMediaSubsession::createNewStreamSource(), MPEG1or2DemuxedServerMediaSubsession::createNewStreamSource(), MediaSubsession::deInitiate(), MediaSubsession::initiate(), MPEG1or2ProgramStreamFileDuration(), MPEG1or2Demux::noteElementaryStreamDeletion(), ByteStreamMultiFileSource::onSourceClosure1(), StreamState::reclaim(), RTSPServer::removeServerMediaSession(), OnDemandServerMediaSubsession::sdpLines(), shutdown(), H264VideoRTPSink::stopPlaying(), subsessionAfterPlaying(), ClientTrickPlayState::updateStateOnScaleChange(), AMRDeinterleaver::~AMRDeinterleaver(), ByteStreamMultiFileSource::~ByteStreamMultiFileSource(), DarwinInjector::~DarwinInjector(), FramedFilter::~FramedFilter(), H264VideoRTPSink::~H264VideoRTPSink(), InputESSourceRecord::~InputESSourceRecord(), MPEG1or2Demux::~MPEG1or2Demux(), MPEG1or2FileServerDemux::~MPEG1or2FileServerDemux(), MPEG2TransportFileServerMediaSubsession::~MPEG2TransportFileServerMediaSubsession(), MPEG2TransportStreamFromPESSource::~MPEG2TransportStreamFromPESSource(), ServerMediaSession::~ServerMediaSession(), and ServerMediaSubsession::~ServerMediaSubsession().

00076                                                           {
00077   MediaLookupTable::ourMedia(env)->remove(name);
00078 }

void Medium::close ( Medium * medium ) [static, inherited]

Definition at line 80 of file Media.cpp.

References Medium::close(), Medium::envir(), Medium::name(), and NULL.

00080                                  {
00081   if (medium == NULL) return;
00082
00083   close(medium->envir(), medium->name());
00084 }

UsageEnvironment& Medium::envir ( ) const [inline, inherited]

Definition at line 59 of file Media.hh.

References Medium::fEnviron.

AVIFileSink Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Member Functions

Static Private Member Functions

Private Attributes

Friends

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation
