RTCPInstance Class Reference

#include <RTCP.hh>

Inheritance diagram for RTCPInstance:

Inheritance graph
[legend]
Collaboration diagram for RTCPInstance:

Collaboration graph
[legend]

Public Member Functions

unsigned numMembers () const
void setByeHandler (TaskFunc *handlerTask, void *clientData, Boolean handleActiveParticipantsOnly=True)
void setSRHandler (TaskFunc *handlerTask, void *clientData)
void setRRHandler (TaskFunc *handlerTask, void *clientData)
void setSpecificRRHandler (netAddressBits fromAddress, Port fromPort, TaskFunc *handlerTask, void *clientData)
Groupsock * RTCPgs () const
void setStreamSocket (int sockNum, unsigned char streamChannelId)
void addStreamSocket (int sockNum, unsigned char streamChannelId)
void removeStreamSocket (int sockNum, unsigned char streamChannelId)
void setAuxilliaryReadHandler (AuxHandlerFunc *handlerFunc, void *handlerClientData)
void schedule (double nextTime)
void reschedule (double nextTime)
void sendReport ()
void sendBYE ()
int typeOfEvent ()
int sentPacketSize ()
int packetType ()
int receivedPacketSize ()
int checkNewSSRC ()
void removeLastReceivedSSRC ()
void removeSSRC (u_int32_t ssrc, Boolean alsoRemoveStats)
UsageEnvironment & envir () const
char const * name () const
virtual Boolean isSource () const
virtual Boolean isSink () const
virtual Boolean isRTSPClient () const
virtual Boolean isRTSPServer () const
virtual Boolean isMediaSession () const
virtual Boolean isServerMediaSession () const
virtual Boolean isDarwinInjector () const

Static Public Member Functions

static RTCPInstance * createNew (UsageEnvironment &env, Groupsock *RTCPgs, unsigned totSessionBW, unsigned char const *cname, RTPSink *sink, RTPSource const *source, Boolean isSSMSource=False)
static Boolean lookupByName (UsageEnvironment &env, char const *instanceName, RTCPInstance *&resultInstance)
static Boolean lookupByName (UsageEnvironment &env, char const *mediumName, Medium *&resultMedium)
static void close (UsageEnvironment &env, char const *mediumName)
static void close (Medium *medium)

Protected Member Functions

 RTCPInstance (UsageEnvironment &env, Groupsock *RTPgs, unsigned totSessionBW, unsigned char const *cname, RTPSink *sink, RTPSource const *source, Boolean isSSMSource)
virtual ~RTCPInstance ()
TaskToken & nextTask ()

Private Member Functions

virtual Boolean isRTCPInstance () const
void addReport ()
void addSR ()
void addRR ()
void enqueueCommonReportPrefix (unsigned char packetType, u_int32_t SSRC, unsigned numExtraWords=0)
void enqueueCommonReportSuffix ()
void enqueueReportBlock (RTPReceptionStats *receptionStats)
void addSDES ()
void addBYE ()
void sendBuiltPacket ()
void onExpire1 ()
void incomingReportHandler1 ()
void onReceive (int typeOfPacket, int totPacketSize, u_int32_t ssrc)
void unsetSpecificRRHandler (netAddressBits fromAddress, Port fromPort)

Static Private Member Functions

static void onExpire (RTCPInstance *instance)
static void incomingReportHandler (RTCPInstance *instance, int)

Private Attributes

unsigned char * fInBuf
OutPacketBuffer * fOutBuf
RTPInterface fRTCPInterface
unsigned fTotSessionBW
RTPSink * fSink
RTPSource const * fSource
Boolean fIsSSMSource
SDESItem fCNAME
RTCPMemberDatabase * fKnownMembers
unsigned fOutgoingReportCount
double fAveRTCPSize
int fIsInitial
double fPrevReportTime
double fNextReportTime
int fPrevNumMembers
int fLastSentSize
int fLastReceivedSize
u_int32_t fLastReceivedSSRC
int fTypeOfEvent
int fTypeOfPacket
Boolean fHaveJustSentPacket
unsigned fLastPacketSentSize
TaskFunc * fByeHandlerTask
void * fByeHandlerClientData
Boolean fByeHandleActiveParticipantsOnly
TaskFunc * fSRHandlerTask
void * fSRHandlerClientData
TaskFunc * fRRHandlerTask
void * fRRHandlerClientData
AddressPortLookupTable * fSpecificRRHandlerTable

Detailed Description

Definition at line 44 of file RTCP.hh.

Constructor & Destructor Documentation

RTCPInstance::RTCPInstance ( UsageEnvironment &  env,
Groupsock *  RTPgs,
unsigned  totSessionBW,
unsigned char const *  cname,
RTPSink *  sink,
RTPSource const *  source,
Boolean  isSSMSource
) [protected]

Definition at line 120 of file RTCP.cpp.

References dTimeNow(), env, EVENT_REPORT, fInBuf, fKnownMembers, fNextReportTime, fOutBuf, fPrevReportTime, fRTCPInterface, fTotSessionBW, fTypeOfEvent, incomingReportHandler(), maxPacketSize, OutPacketBuffer::maxSize, Groupsock::multicastSendOnly(), NULL, onExpire(), preferredPacketSize, RTCPgs(), and RTPInterface::startNetworkReading().

Referenced by createNew().

00125   : Medium(env), fRTCPInterface(this, RTCPgs), fTotSessionBW(totSessionBW),
00126     fSink(sink), fSource(source), fIsSSMSource(isSSMSource),
00127     fCNAME(RTCP_SDES_CNAME, cname), fOutgoingReportCount(1),
00128     fAveRTCPSize(0), fIsInitial(1), fPrevNumMembers(0),
00129     fLastSentSize(0), fLastReceivedSize(0), fLastReceivedSSRC(0),
00130     fTypeOfEvent(EVENT_UNKNOWN), fTypeOfPacket(PACKET_UNKNOWN_TYPE),
00131     fHaveJustSentPacket(False), fLastPacketSentSize(0),
00132     fByeHandlerTask(NULL), fByeHandlerClientData(NULL),
00133     fSRHandlerTask(NULL), fSRHandlerClientData(NULL),
00134     fRRHandlerTask(NULL), fRRHandlerClientData(NULL),
00135     fSpecificRRHandlerTable(NULL) {
00136 #ifdef DEBUG
00137   fprintf(stderr, "RTCPInstance[%p]::RTCPInstance()\n", this);
00138 #endif
00139   if (fTotSessionBW == 0) { // not allowed!
00140     env << "RTCPInstance::RTCPInstance error: totSessionBW parameter should not be zero!\n";
00141     fTotSessionBW = 1;
00142   }
00143
00144   if (isSSMSource) RTCPgs->multicastSendOnly(); // don't receive multicast
00145
00146   double timeNow = dTimeNow();
00147   fPrevReportTime = fNextReportTime = timeNow;
00148
00149   fKnownMembers = new RTCPMemberDatabase(*this);
00150   fInBuf = new unsigned char[maxPacketSize];
00151   if (fKnownMembers == NULL || fInBuf == NULL) return;
00152
00153   // A hack to save buffer space, because RTCP packets are always small:
00154   unsigned savedMaxSize = OutPacketBuffer::maxSize;
00155   OutPacketBuffer::maxSize = maxPacketSize;
00156   fOutBuf = new OutPacketBuffer(preferredPacketSize, maxPacketSize);
00157   OutPacketBuffer::maxSize = savedMaxSize;
00158   if (fOutBuf == NULL) return;
00159
00160   // Arrange to handle incoming reports from others:
00161   TaskScheduler::BackgroundHandlerProc* handler
00162     = (TaskScheduler::BackgroundHandlerProc*)&incomingReportHandler;
00163   fRTCPInterface.startNetworkReading(handler);
00164
00165   // Send our first report.
00166   fTypeOfEvent = EVENT_REPORT;
00167   onExpire(this);
00168 }

RTCPInstance::~RTCPInstance (  )  [protected, virtual]

Definition at line 175 of file RTCP.cpp.

References EVENT_BYE, fInBuf, fKnownMembers, fOutBuf, fRTCPInterface, fSpecificRRHandlerTable, fTypeOfEvent, iter, MediaSubsessionIterator::next(), NULL, sendBYE(), and RTPInterface::stopNetworkReading().

00175                             {
00176 #ifdef DEBUG
00177   fprintf(stderr, "RTCPInstance[%p]::~RTCPInstance()\n", this);
00178 #endif
00179   // Turn off background read handling:
00180   fRTCPInterface.stopNetworkReading();
00181
00182   // Begin by sending a BYE.  We have to do this immediately, without
00183   // 'reconsideration', because "this" is going away.
00184   fTypeOfEvent = EVENT_BYE; // not used, but...
00185   sendBYE();
00186
00187   if (fSpecificRRHandlerTable != NULL) {
00188     AddressPortLookupTable::Iterator iter(*fSpecificRRHandlerTable);
00189     RRHandlerRecord* rrHandler;
00190     while ((rrHandler = (RRHandlerRecord*)iter.next()) != NULL) {
00191       delete rrHandler;
00192     }
00193     delete fSpecificRRHandlerTable;
00194   }
00195
00196   delete fKnownMembers;
00197   delete fOutBuf;
00198   delete[] fInBuf;
00199 }

Member Function Documentation

RTCPInstance * RTCPInstance::createNew ( UsageEnvironment &  env,
Groupsock *  RTCPgs,
unsigned  totSessionBW,
unsigned char const *  cname,
RTPSink *  sink,
RTPSource const *  source,
Boolean  isSSMSource = False
) [static]

Definition at line 201 of file RTCP.cpp.

References env, RTCPgs(), and RTCPInstance().

Referenced by MediaSubsession::initiate(), main(), and StreamState::startPlaying().

00205                                                            {
00206   return new RTCPInstance(env, RTCPgs, totSessionBW, cname, sink, source,
00207                           isSSMSource);
00208 }

Boolean RTCPInstance::lookupByName ( UsageEnvironment &  env,
char const *  instanceName,
RTCPInstance *&  resultInstance
) [static]

Definition at line 210 of file RTCP.cpp.

References env, False, Medium::isRTCPInstance(), Medium::lookupByName(), NULL, and True.

00212                                                                   {
00213   resultInstance = NULL; // unless we succeed
00214
00215   Medium* medium;
00216   if (!Medium::lookupByName(env, instanceName, medium)) return False;
00217
00218   if (!medium->isRTCPInstance()) {
00219     env.setResultMsg(instanceName, " is not a RTCP instance");
00220     return False;
00221   }
00222
00223   resultInstance = (RTCPInstance*)medium;
00224   return True;
00225 }

unsigned RTCPInstance::numMembers (  )  const

Definition at line 231 of file RTCP.cpp.

References fKnownMembers, NULL, and RTCPMemberDatabase::numMembers().

Referenced by onExpire1().

00231                                         {
00232   if (fKnownMembers == NULL) return 0;
00233
00234   return fKnownMembers->numMembers();
00235 }

void RTCPInstance::setByeHandler ( TaskFunc *  handlerTask,
void *  clientData,
Boolean  handleActiveParticipantsOnly = True
)

Definition at line 237 of file RTCP.cpp.

References fByeHandleActiveParticipantsOnly, fByeHandlerClientData, and fByeHandlerTask.

Referenced by AVIFileSink::AVIFileSink(), main(), and QuickTimeFileSink::QuickTimeFileSink().

00238                                                                        {
00239   fByeHandlerTask = handlerTask;
00240   fByeHandlerClientData = clientData;
00241   fByeHandleActiveParticipantsOnly = handleActiveParticipantsOnly;
00242 }

void RTCPInstance::setSRHandler ( TaskFunc *  handlerTask,
void *  clientData
)

Definition at line 244 of file RTCP.cpp.

References fSRHandlerClientData, and fSRHandlerTask.

00244                                                                        {
00245   fSRHandlerTask = handlerTask;
00246   fSRHandlerClientData = clientData;
00247 }

void RTCPInstance::setRRHandler ( TaskFunc *  handlerTask,
void *  clientData
)

Definition at line 249 of file RTCP.cpp.

References fRRHandlerClientData, and fRRHandlerTask.

00249                                                                        {
00250   fRRHandlerTask = handlerTask;
00251   fRRHandlerClientData = clientData;
00252 }

void RTCPInstance::setSpecificRRHandler ( netAddressBits  fromAddress,
Port  fromPort,
TaskFunc *  handlerTask,
void *  clientData
)

Definition at line 255 of file RTCP.cpp.

References AddressPortLookupTable::Add(), fSpecificRRHandlerTable, NULL, RRHandlerRecord::rrHandlerClientData, RRHandlerRecord::rrHandlerTask, and unsetSpecificRRHandler().

Referenced by StreamState::endPlaying(), and StreamState::startPlaying().

00256                                                                 {
00257   if (handlerTask == NULL && clientData == NULL) {
00258     unsetSpecificRRHandler(fromAddress, fromPort);
00259     return;
00260   }
00261
00262   RRHandlerRecord* rrHandler = new RRHandlerRecord;
00263   rrHandler->rrHandlerTask = handlerTask;
00264   rrHandler->rrHandlerClientData = clientData;
00265   if (fSpecificRRHandlerTable == NULL) {
00266     fSpecificRRHandlerTable = new AddressPortLookupTable;
00267   }
00268   fSpecificRRHandlerTable->Add(fromAddress, (~0), fromPort, rrHandler);
00269 }

Groupsock* RTCPInstance::RTCPgs (  )  const [inline]

Definition at line 82 of file RTCP.hh.

References fRTCPInterface, and RTPInterface::gs().

Referenced by createNew(), PassiveServerMediaSubsession::getStreamParameters(), incomingReportHandler1(), and RTCPInstance().

00082 { return fRTCPInterface.gs(); }

void RTCPInstance::setStreamSocket ( int  sockNum,
unsigned char  streamChannelId
)

Definition at line 283 of file RTCP.cpp.

References fRTCPInterface, incomingReportHandler(), RTPInterface::setStreamSocket(), RTPInterface::startNetworkReading(), and RTPInterface::stopNetworkReading().

Referenced by DarwinInjector::setDestination(), and RTSPClient::setupMediaSubsession().

00284                                                                   {
00285   // Turn off background read handling:
00286   fRTCPInterface.stopNetworkReading();
00287
00288   // Switch to RTCP-over-TCP:
00289   fRTCPInterface.setStreamSocket(sockNum, streamChannelId);
00290
00291   // Turn background reading back on:
00292   TaskScheduler::BackgroundHandlerProc* handler
00293     = (TaskScheduler::BackgroundHandlerProc*)&incomingReportHandler;
00294   fRTCPInterface.startNetworkReading(handler);
00295 }

void RTCPInstance::addStreamSocket ( int  sockNum,
unsigned char  streamChannelId
)

Definition at line 297 of file RTCP.cpp.

References fRTCPInterface, incomingReportHandler(), RTPInterface::setStreamSocket(), RTPInterface::startNetworkReading(), and RTPInterface::stopNetworkReading().

Referenced by StreamState::startPlaying().

00298                                                                   {
00299   // First, turn off background read handling for the default (UDP) socket:
00300   fRTCPInterface.stopNetworkReading();
00301
00302   // Add the RTCP-over-TCP interface:
00303   fRTCPInterface.setStreamSocket(sockNum, streamChannelId);
00304
00305   // Turn on background reading for this socket (in case it's not on already):
00306   TaskScheduler::BackgroundHandlerProc* handler
00307     = (TaskScheduler::BackgroundHandlerProc*)&incomingReportHandler;
00308   fRTCPInterface.startNetworkReading(handler);
00309 }

void RTCPInstance::removeStreamSocket ( int  sockNum,
unsigned char  streamChannelId
) [inline]

Definition at line 86 of file RTCP.hh.

References fRTCPInterface, and RTPInterface::removeStreamSocket().

Referenced by StreamState::endPlaying().

00086                                                                       {
00087     fRTCPInterface.removeStreamSocket(sockNum, streamChannelId);
00088   }

void RTCPInstance::setAuxilliaryReadHandler ( AuxHandlerFunc *  handlerFunc,
void *  handlerClientData
) [inline]

Definition at line 91 of file RTCP.hh.

References fRTCPInterface, and RTPInterface::setAuxilliaryReadHandler().

00092                                                          {
00093     fRTCPInterface.setAuxilliaryReadHandler(handlerFunc,
00094                                             handlerClientData);
00095   }

Boolean RTCPInstance::isRTCPInstance (  )  const [private, virtual]

Reimplemented from Medium.

Definition at line 227 of file RTCP.cpp.

References True.

00227                                            {
00228   return True;
00229 }

void RTCPInstance::addReport (  )  [private]

Definition at line 669 of file RTCP.cpp.

References addRR(), addSR(), fSink, fSource, and NULL.

Referenced by sendBYE(), and sendReport().

00669                              {
00670   // Include a SR or a RR, depending on whether we
00671   // have an associated sink or source:
00672   if (fSink != NULL) {
00673     addSR();
00674   } else if (fSource != NULL) {
00675     addRR();
00676   }
00677 }

void RTCPInstance::addSR (  )  [private]

Definition at line 679 of file RTCP.cpp.

References RTPSink::convertToRTPTimestamp(), enqueueCommonReportPrefix(), enqueueCommonReportSuffix(), OutPacketBuffer::enqueueWord(), fOutBuf, fSink, NULL, RTPSink::octetCount(), RTPSink::packetCount(), RTCP_PT_SR, and RTPSink::SSRC().

Referenced by addReport().

00679                          {
00680   // ASSERT: fSink != NULL
00681
00682   enqueueCommonReportPrefix(RTCP_PT_SR, fSink->SSRC(),
00683                             5 /* extra words in a SR */);
00684
00685   // Now, add the 'sender info' for our sink
00686
00687   // Insert the NTP and RTP timestamps for the 'wallclock time':
00688   struct timeval timeNow;
00689   gettimeofday(&timeNow, NULL);
00690   fOutBuf->enqueueWord(timeNow.tv_sec + 0x83AA7E80);
00691       // NTP timestamp most-significant word (1970 epoch -> 1900 epoch)
00692   double fractionalPart = (timeNow.tv_usec/15625.0)*0x04000000; // 2^32/10^6
00693   fOutBuf->enqueueWord((unsigned)(fractionalPart+0.5));
00694       // NTP timestamp least-significant word
00695   unsigned rtpTimestamp = fSink->convertToRTPTimestamp(timeNow);
00696   fOutBuf->enqueueWord(rtpTimestamp); // RTP ts
00697
00698   // Insert the packet and byte counts:
00699   fOutBuf->enqueueWord(fSink->packetCount());
00700   fOutBuf->enqueueWord(fSink->octetCount());
00701
00702   enqueueCommonReportSuffix();
00703 }

void RTCPInstance::addRR (  )  [private]

Definition at line 705 of file RTCP.cpp.

References enqueueCommonReportPrefix(), enqueueCommonReportSuffix(), fSource, RTCP_PT_RR, and RTPSource::SSRC().

Referenced by addReport().

00705                          {
00706   // ASSERT: fSource != NULL
00707
00708   enqueueCommonReportPrefix(RTCP_PT_RR, fSource->SSRC());
00709   enqueueCommonReportSuffix();
00710 }

void RTCPInstance::enqueueCommonReportPrefix ( unsigned char  packetType,
u_int32_t  SSRC,
unsigned  numExtraWords = 0
) [private]

Referenced by addRR(), and addSR().

void RTCPInstance::enqueueCommonReportSuffix (  )  [private]

Definition at line 737 of file RTCP.cpp.

References enqueueReportBlock(), fSource, RTPReceptionStatsDB::Iterator::next(), NULL, RTPSource::receptionStatsDB(), and RTPReceptionStatsDB::reset().

Referenced by addRR(), and addSR().

00737                                              {
00738   // Output the report blocks for each source:
00739   if (fSource != NULL) {
00740     RTPReceptionStatsDB& allReceptionStats
00741       = fSource->receptionStatsDB();
00742
00743     RTPReceptionStatsDB::Iterator iterator(allReceptionStats);
00744     while (1) {
00745       RTPReceptionStats* receptionStats = iterator.next();
00746       if (receptionStats == NULL) break;
00747       enqueueReportBlock(receptionStats);
00748     }
00749
00750     allReceptionStats.reset(); // because we have just generated a report
00751   }
00752 }

void RTCPInstance::enqueueReportBlock ( RTPReceptionStats *  receptionStats  )  [private]

Definition at line 755 of file RTCP.cpp.

References RTPReceptionStats::baseExtSeqNumReceived(), OutPacketBuffer::enqueueWord(), fOutBuf, RTPReceptionStats::highestExtSeqNumReceived(), RTPReceptionStats::jitter(), RTPReceptionStats::lastReceivedSR_NTPlsw(), RTPReceptionStats::lastReceivedSR_NTPmsw(), RTPReceptionStats::lastReceivedSR_time(), RTPReceptionStats::lastResetExtSeqNumReceived(), NULL, RTPReceptionStats::numPacketsReceivedSinceLastReset(), RTPReceptionStats::SSRC(), and RTPReceptionStats::totNumPacketsReceived().

Referenced by enqueueCommonReportSuffix().

00755                                                          {
00756   fOutBuf->enqueueWord(stats->SSRC());
00757
00758   unsigned highestExtSeqNumReceived = stats->highestExtSeqNumReceived();
00759
00760   unsigned totNumExpected
00761     = highestExtSeqNumReceived - stats->baseExtSeqNumReceived();
00762   int totNumLost = totNumExpected - stats->totNumPacketsReceived();
00763   // 'Clamp' this loss number to a 24-bit signed value:
00764   if (totNumLost > 0x007FFFFF) {
00765     totNumLost = 0x007FFFFF;
00766   } else if (totNumLost < 0) {
00767     if (totNumLost < -0x00800000) totNumLost = 0x00800000; // unlikely, but...
00768     totNumLost &= 0x00FFFFFF;
00769   }
00770
00771   unsigned numExpectedSinceLastReset
00772     = highestExtSeqNumReceived - stats->lastResetExtSeqNumReceived();
00773   int numLostSinceLastReset
00774     = numExpectedSinceLastReset - stats->numPacketsReceivedSinceLastReset();
00775   unsigned char lossFraction;
00776   if (numExpectedSinceLastReset == 0 || numLostSinceLastReset < 0) {
00777     lossFraction = 0;
00778   } else {
00779     lossFraction = (unsigned char)
00780       ((numLostSinceLastReset << 8) / numExpectedSinceLastReset);
00781   }
00782
00783   fOutBuf->enqueueWord((lossFraction<<24) | totNumLost);
00784   fOutBuf->enqueueWord(highestExtSeqNumReceived);
00785
00786   fOutBuf->enqueueWord(stats->jitter());
00787
00788   unsigned NTPmsw = stats->lastReceivedSR_NTPmsw();
00789   unsigned NTPlsw = stats->lastReceivedSR_NTPlsw();
00790   unsigned LSR = ((NTPmsw&0xFFFF)<<16)|(NTPlsw>>16); // middle 32 bits
00791   fOutBuf->enqueueWord(LSR);
00792
00793   // Figure out how long has elapsed since the last SR rcvd from this src:
00794   struct timeval const& LSRtime = stats->lastReceivedSR_time(); // "last SR"
00795   struct timeval timeNow, timeSinceLSR;
00796   gettimeofday(&timeNow, NULL);
00797   if (timeNow.tv_usec < LSRtime.tv_usec) {
00798     timeNow.tv_usec += 1000000;
00799     timeNow.tv_sec -= 1;
00800   }
00801   timeSinceLSR.tv_sec = timeNow.tv_sec - LSRtime.tv_sec;
00802   timeSinceLSR.tv_usec = timeNow.tv_usec - LSRtime.tv_usec;
00803   // The enqueued time is in units of 1/65536 seconds.
00804   // (Note that 65536/1000000 == 1024/15625)
00805   unsigned DLSR;
00806   if (LSR == 0) {
00807     DLSR = 0;
00808   } else {
00809     DLSR = (timeSinceLSR.tv_sec<<16)
00810          | ( (((timeSinceLSR.tv_usec<<11)+15625)/31250) & 0xFFFF);
00811   }
00812   fOutBuf->enqueueWord(DLSR);
00813 }

void RTCPInstance::addSDES (  )  [private]

Definition at line 815 of file RTCP.cpp.

References OutPacketBuffer::curPacketSize(), SDESItem::data(), OutPacketBuffer::enqueue(), OutPacketBuffer::enqueueWord(), fCNAME, fOutBuf, fSink, fSource, NULL, RTCP_PT_SDES, RTPSink::SSRC(), RTPSource::SSRC(), and SDESItem::totalSize().

Referenced by sendReport().

00815                            {
00816   // For now we support only the CNAME item; later support more #####
00817
00818   // Begin by figuring out the size of the entire SDES report:
00819   unsigned numBytes = 4;
00820       // counts the SSRC, but not the header; it'll get subtracted out
00821   numBytes += fCNAME.totalSize(); // includes id and length
00822   numBytes += 1; // the special END item
00823
00824   unsigned num4ByteWords = (numBytes + 3)/4;
00825
00826   unsigned rtcpHdr = 0x81000000; // version 2, no padding, 1 SSRC chunk
00827   rtcpHdr |= (RTCP_PT_SDES<<16);
00828   rtcpHdr |= num4ByteWords;
00829   fOutBuf->enqueueWord(rtcpHdr);
00830
00831   if (fSource != NULL) {
00832     fOutBuf->enqueueWord(fSource->SSRC());
00833   } else if (fSink != NULL) {
00834     fOutBuf->enqueueWord(fSink->SSRC());
00835   }
00836
00837   // Add the CNAME:
00838   fOutBuf->enqueue(fCNAME.data(), fCNAME.totalSize());
00839
00840   // Add the 'END' item (i.e., a zero byte), plus any more needed to pad:
00841   unsigned numPaddingBytesNeeded = 4 - (fOutBuf->curPacketSize() % 4);
00842   unsigned char const zero = '\0';
00843   while (numPaddingBytesNeeded-- > 0) fOutBuf->enqueue(&zero, 1);
00844 }

void RTCPInstance::addBYE (  )  [private]

Definition at line 846 of file RTCP.cpp.

References OutPacketBuffer::enqueueWord(), fOutBuf, fSink, fSource, NULL, RTCP_PT_BYE, RTPSink::SSRC(), and RTPSource::SSRC().

Referenced by sendBYE().

00846                           {
00847   unsigned rtcpHdr = 0x81000000; // version 2, no padding, 1 SSRC
00848   rtcpHdr |= (RTCP_PT_BYE<<16);
00849   rtcpHdr |= 1; // 2 32-bit words total (i.e., with 1 SSRC)
00850   fOutBuf->enqueueWord(rtcpHdr);
00851
00852   if (fSource != NULL) {
00853     fOutBuf->enqueueWord(fSource->SSRC());
00854   } else if (fSink != NULL) {
00855     fOutBuf->enqueueWord(fSink->SSRC());
00856   }
00857 }

void RTCPInstance::sendBuiltPacket (  )  [private]

Definition at line 625 of file RTCP.cpp.

References OutPacketBuffer::curPacketSize(), fHaveJustSentPacket, fLastPacketSentSize, fLastSentSize, fOutBuf, fRTCPInterface, IP_UDP_HDR_SIZE, OutPacketBuffer::packet(), OutPacketBuffer::resetOffset(), RTPInterface::sendPacket(), and True.

Referenced by sendBYE(), and sendReport().

00625                                    {
00626 #ifdef DEBUG
00627   fprintf(stderr, "sending RTCP packet\n");
00628   unsigned char* p = fOutBuf->packet();
00629   for (unsigned i = 0; i < fOutBuf->curPacketSize(); ++i) {
00630     if (i%4 == 0) fprintf(stderr," ");
00631     fprintf(stderr, "%02x", p[i]);
00632   }
00633   fprintf(stderr, "\n");
00634 #endif
00635   unsigned reportSize = fOutBuf->curPacketSize();
00636   fRTCPInterface.sendPacket(fOutBuf->packet(), reportSize);
00637   fOutBuf->resetOffset();
00638
00639   fLastSentSize = IP_UDP_HDR_SIZE + reportSize;
00640   fHaveJustSentPacket = True;
00641   fLastPacketSentSize = reportSize;
00642 }

void RTCPInstance::onExpire ( RTCPInstance *  instance  )  [static, private]

Definition at line 663 of file RTCP.cpp.

References onExpire1().

Referenced by RTCPInstance(), and schedule().

00663                                                   {
00664   instance->onExpire1();
00665 }

void RTCPInstance::onExpire1 (  )  [private]

Definition at line 876 of file RTCP.cpp.

References dTimeNow(), fAveRTCPSize, fIsInitial, fPrevNumMembers, fPrevReportTime, fSink, fTotSessionBW, NULL, numMembers(), and OnExpire().

Referenced by onExpire().

00876                              {
00877   // Note: fTotSessionBW is kbits per second
00878   double rtcpBW = 0.05*fTotSessionBW*1024/8; // -> bytes per second
00879
00880   OnExpire(this, // event
00881            numMembers(), // members
00882            (fSink != NULL) ? 1 : 0, // senders
00883            rtcpBW, // rtcp_bw
00884            (fSink != NULL) ? 1 : 0, // we_sent
00885            &
