live: BasicUDPSource Class Reference

typedef void( FramedSource::afterGettingFunc)(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds) [inherited]

Definition at line 36 of file FramedSource.hh.

typedef void( FramedSource::onCloseFunc)(void *clientData) [inherited]

Definition at line 40 of file FramedSource.hh.

BasicUDPSource::~BasicUDPSource ( ) [virtual]

Definition at line 41 of file BasicUDPSource.cpp.

References Medium::envir(), fInputGS, Socket::socketNum(), UsageEnvironment::taskScheduler(), and TaskScheduler::turnOffBackgroundReadHandling().

00041                                {
00042   envir().taskScheduler().turnOffBackgroundReadHandling(fInputGS->socketNum());
00043 }

BasicUDPSource::BasicUDPSource	(	UsageEnvironment &	env,
		Groupsock *	inputGS
	)			`[private]`

Definition at line 29 of file BasicUDPSource.cpp.

References env, fInputGS, increaseReceiveBufferTo(), makeSocketNonBlocking(), and Socket::socketNum().

Referenced by createNew().

00030   : FramedSource(env), fInputGS(inputGS), fHaveStartedReading(False) {
00031   // Try to use a large receive buffer (in the OS):
00032   increaseReceiveBufferTo(env, inputGS->socketNum(), 50*1024);
00033
00034   // Make the socket non-blocking, even though it will be read from only asynchronously, when packets arrive.
00035   // The reason for this is that, in some OSs, reads on a blocking socket can (allegedly) sometimes block,
00036   // even if the socket was previously reported (e.g., by "select()") as having data available.
00037   // (This can supposedly happen if the UDP checksum fails, for example.)
00038   makeSocketNonBlocking(fInputGS->socketNum());
00039 }

BasicUDPSource * BasicUDPSource::createNew	(	UsageEnvironment &	env,
		Groupsock *	inputGS
	)			`[static]`

Definition at line 24 of file BasicUDPSource.cpp.

References BasicUDPSource(), and env.

Referenced by MediaSubsession::initiate(), and main().

00025                                                             {
00026   return new BasicUDPSource(env, inputGS);
00027 }

Groupsock* BasicUDPSource::gs ( ) const [inline]

Definition at line 37 of file BasicUDPSource.hh.

References fInputGS.

00037 { return fInputGS; }

void BasicUDPSource::incomingPacketHandler	(	BasicUDPSource *	source,
		int	mask
	)			`[static, private]`

Definition at line 60 of file BasicUDPSource.cpp.

References incomingPacketHandler1().

Referenced by doGetNextFrame().

00060                                                                               {
00061   source->incomingPacketHandler1();
00062 }

void BasicUDPSource::incomingPacketHandler1 ( ) [private]

Definition at line 64 of file BasicUDPSource.cpp.

References FramedSource::afterGetting(), FramedSource::fFrameSize, fInputGS, FramedSource::fMaxSize, FramedSource::fTo, Groupsock::handleRead(), and FramedSource::isCurrentlyAwaitingData().

Referenced by incomingPacketHandler().

00064                                             {
00065   if (!isCurrentlyAwaitingData()) return; // we're not ready for the data yet
00066
00067   // Read the packet into our desired destination:
00068   struct sockaddr_in fromAddress;
00069   if (!fInputGS->handleRead(fTo, fMaxSize, fFrameSize, fromAddress)) return;
00070
00071   // Tell our client that we have new data:
00072   afterGetting(this); // we're preceded by a net read; no infinite recursion
00073 }

void BasicUDPSource::doGetNextFrame ( ) [private, virtual]

Implements FramedSource.

Definition at line 45 of file BasicUDPSource.cpp.

References Medium::envir(), fHaveStartedReading, fInputGS, incomingPacketHandler(), Socket::socketNum(), UsageEnvironment::taskScheduler(), True, and TaskScheduler::turnOnBackgroundReadHandling().

00045                                     {
00046   if (!fHaveStartedReading) {
00047     // Await incoming packets:
00048     envir().taskScheduler().turnOnBackgroundReadHandling(fInputGS->socketNum(),
00049          (TaskScheduler::BackgroundHandlerProc*)&incomingPacketHandler, this);
00050     fHaveStartedReading = True;
00051   }
00052 }

void BasicUDPSource::doStopGettingFrames ( ) [private, virtual]

Reimplemented from FramedSource.

Definition at line 54 of file BasicUDPSource.cpp.

References Medium::envir(), False, fHaveStartedReading, fInputGS, Socket::socketNum(), UsageEnvironment::taskScheduler(), and TaskScheduler::turnOffBackgroundReadHandling().

00054                                          {
00055   envir().taskScheduler().turnOffBackgroundReadHandling(fInputGS->socketNum());
00056   fHaveStartedReading = False;
00057 }

Boolean FramedSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		FramedSource *&	resultSource
	)			`[static, inherited]`

Definition at line 41 of file FramedSource.cpp.

References env, False, MediaSource::isFramedSource(), MediaSource::lookupByName(), NULL, and True.

Referenced by MP3ADUinterleaverBase::getInputSource().

00042                                                                 {
00043   resultSource = NULL; // unless we succeed
00044
00045   MediaSource* source;
00046   if (!MediaSource::lookupByName(env, sourceName, source)) return False;
00047
00048   if (!source->isFramedSource()) {
00049     env.setResultMsg(sourceName, " is not a framed source");
00050     return False;
00051   }
00052
00053   resultSource = (FramedSource*)source;
00054   return True;
00055 }

Boolean MediaSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		MediaSource *&	resultSource
	)			`[static, inherited]`

Definition at line 62 of file MediaSource.cpp.

References env, False, Medium::isSource(), Medium::lookupByName(), NULL, and True.

Referenced by RTPSource::lookupByName(), and FramedSource::lookupByName().

00064                                                               {
00065   resultSource = NULL; // unless we succeed
00066
00067   Medium* medium;
00068   if (!Medium::lookupByName(env, sourceName, medium)) return False;
00069
00070   if (!medium->isSource()) {
00071     env.setResultMsg(sourceName, " is not a media source");
00072     return False;
00073   }
00074
00075   resultSource = (MediaSource*)medium;
00076   return True;
00077 }

Boolean Medium::lookupByName	(	UsageEnvironment &	env,
		char const *	mediumName,
		Medium *&	resultMedium
	)			`[static, inherited]`

Definition at line 65 of file Media.cpp.

References env, False, MediaLookupTable::lookup(), NULL, MediaLookupTable::ourMedia(), UsageEnvironment::setResultMsg(), and True.

Referenced by ServerMediaSession::lookupByName(), RTSPServer::lookupByName(), RTSPClient::lookupByName(), RTCPInstance::lookupByName(), MediaSource::lookupByName(), MediaSink::lookupByName(), MediaSession::lookupByName(), and DarwinInjector::lookupByName().

00066                                                          {
00067   resultMedium = MediaLookupTable::ourMedia(env)->lookup(mediumName);
00068   if (resultMedium == NULL) {
00069     env.setResultMsg("Medium ", mediumName, " does not exist");
00070     return False;
00071   }
00072
00073   return True;
00074 }

void FramedSource::getNextFrame	(	unsigned char *	to,
		unsigned	maxSize,
		afterGettingFunc *	afterGettingFunc,
		void *	afterGettingClientData,
		onCloseFunc *	onCloseFunc,
		void *	onCloseClientData
	)			`[inherited]`

Definition at line 57 of file FramedSource.cpp.

References FramedSource::doGetNextFrame(), Medium::envir(), FramedSource::fAfterGettingClientData, FramedSource::fAfterGettingFunc, FramedSource::fDurationInMicroseconds, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fMaxSize, FramedSource::fNumTruncatedBytes, FramedSource::fOnCloseClientData, FramedSource::fOnCloseFunc, FramedSource::fTo, and True.

00061                                                          {
00062   // Make sure we're not already being read:
00063   if (fIsCurrentlyAwaitingData) {
00064     envir() << "FramedSource[" << this << "]::getNextFrame(): attempting to read more than once at the same time!\n";
00065     exit(1);
00066   }
00067
00068   fTo = to;
00069   fMaxSize = maxSize;
00070   fNumTruncatedBytes = 0; // by default; could be changed by doGetNextFrame()
00071   fDurationInMicroseconds = 0; // by default; could be changed by doGetNextFrame()
00072   fAfterGettingFunc = afterGettingFunc;
00073   fAfterGettingClientData = afterGettingClientData;
00074   fOnCloseFunc = onCloseFunc;
00075   fOnCloseClientData = onCloseClientData;
00076   fIsCurrentlyAwaitingData = True;
00077
00078   doGetNextFrame();
00079 }

void FramedSource::handleClosure ( void * clientData ) [static, inherited]

Definition at line 95 of file FramedSource.cpp.

References False, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fOnCloseClientData, FramedSource::fOnCloseFunc, and NULL.

00095                                                  {
00096   FramedSource* source = (FramedSource*)clientData;
00097   source->fIsCurrentlyAwaitingData = False; // because we got a close instead
00098   if (source->fOnCloseFunc != NULL) {
00099     (*(source->fOnCloseFunc))(source->fOnCloseClientData);
00100   }
00101 }

void FramedSource::stopGettingFrames ( ) [inherited]

Definition at line 103 of file FramedSource.cpp.

References FramedSource::doStopGettingFrames(), False, and FramedSource::fIsCurrentlyAwaitingData.

Referenced by MPEG2TransportStreamFromPESSource::doStopGettingFrames(), FramedFilter::doStopGettingFrames(), AMRDeinterleaver::doStopGettingFrames(), and MediaSink::stopPlaying().

00103                                      {
00104   fIsCurrentlyAwaitingData = False; // indicates that we can be read again
00105
00106   // Perform any specialized action now:
00107   doStopGettingFrames();
00108 }

unsigned FramedSource::maxFrameSize ( ) const [virtual, inherited]

Reimplemented in MPEG1or2DemuxedElementaryStream.

Definition at line 116 of file FramedSource.cpp.

Referenced by StreamParser::ensureValidBytes1().

00116                                           {
00117   // By default, this source has no maximum frame size.
00118   return 0;
00119 }

Boolean FramedSource::isCurrentlyAwaitingData ( ) const [inline, inherited]

Definition at line 60 of file FramedSource.hh.

References FramedSource::fIsCurrentlyAwaitingData.

Referenced by afterPlaying(), InputESSourceRecord::askForNewData(), MPEG2TransportStreamFromESSource::awaitNewBuffer(), QuickTimeFileSink::continuePlaying(), AVIFileSink::continuePlaying(), DeviceSource::deliverFrame(), QCELPDeinterleaver::doGetNextFrame(), AMRDeinterleaver::doGetNextFrame(), ByteStreamFileSource::fileReadableHandler(), and incomingPacketHandler1().

00060 {return fIsCurrentlyAwaitingData;}

void FramedSource::afterGetting ( FramedSource * source ) [static, protected, inherited]

Definition at line 81 of file FramedSource.cpp.

References FramedSource::fAfterGettingClientData, FramedSource::fAfterGettingFunc, False, FramedSource::fDurationInMicroseconds, FramedSource::fFrameSize, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fNumTruncatedBytes, FramedSource::fPresentationTime, and NULL.

00081                                                     {
00082   source->fIsCurrentlyAwaitingData = False;
00083       // indicates that we can be read again
00084       // Note that this needs to be done here, in case the "fAfterFunc"
00085       // called below tries to read another frame (which it usually will)
00086
00087   if (source->fAfterGettingFunc != NULL) {
00088     (*(source->fAfterGettingFunc))(source->fAfterGettingClientData,
00089                                    source->fFrameSize, source->fNumTruncatedBytes,
00090                                    source->fPresentationTime,
00091                                    source->fDurationInMicroseconds);
00092   }
00093 }

void MediaSource::getAttributes ( ) const [virtual, inherited]

Reimplemented in FramedFilter, MP3ADUTranscoder, MP3FileSource, and RTPSource.

Definition at line 79 of file MediaSource.cpp.

References Medium::envir(), and UsageEnvironment::setResultMsg().

Referenced by MP3ADUTranscoder::getAttributes(), and FramedFilter::getAttributes().

00079                                       {
00080   // Default implementation
00081   envir().setResultMsg("");
00082 }

char const * MediaSource::MIMEtype ( ) const [virtual, inherited]

Reimplemented in RawAMRRTPSource, AC3AudioRTPSource, FramedFilter, H261VideoRTPSource, H263plusVideoRTPSource, H264VideoRTPSource, JPEGVideoRTPSource, ADUFromMP3Source, MP3FromADUSource, MP3ADURTPSource, MP3FileSource, MPEG1or2AudioRTPSource, MPEG1or2DemuxedElementaryStream, MPEG1or2VideoRTPSource, MPEG4ESVideoRTPSource, MPEG4GenericRTPSource, MPEG4LATMAudioRTPSource, QuickTimeGenericRTPSource, SimpleRTPSource, and RawQCELPRTPSource.

Definition at line 36 of file MediaSource.cpp.

Referenced by HTTPSink::continuePlaying(), MP3ADUTranscoder::createNew(), MP3FromADUSource::createNew(), ADUFromMP3Source::createNew(), MP3ADUinterleaverBase::getInputSource(), MediaSession::initiateByMediaType(), SimpleRTPSource::MIMEtype(), QuickTimeGenericRTPSource::MIMEtype(), FramedFilter::MIMEtype(), and MPEG1or2DemuxedElementaryStream::MPEG1or2DemuxedElementaryStream().

00036                                         {
00037   return "application/OCTET-STREAM"; // default type
00038 }

Boolean MediaSource::isRTPSource ( ) const [virtual, inherited]

Reimplemented in RTPSource.

Definition at line 43 of file MediaSource.cpp.

References False.

Referenced by RTPSource::lookupByName().

00043                                        {
00044   return False; // default implementation
00045 }

Boolean MediaSource::isMPEG1or2VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in MPEG1or2VideoStreamFramer.

Definition at line 46 of file MediaSource.cpp.

References False.

Referenced by MPEG1or2VideoRTPSink::sourceIsCompatibleWithUs().

00046                                                        {
00047   return False; // default implementation
00048 }

Boolean MediaSource::isMPEG4VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in MPEG4VideoStreamFramer.

Definition at line 49 of file MediaSource.cpp.

References False.

Referenced by MPEG4ESVideoRTPSink::sourceIsCompatibleWithUs().

00049                                                     {
00050   return False; // default implementation
00051 }

Boolean MediaSource::isH264VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in H264VideoStreamFramer.

Definition at line 52 of file MediaSource.cpp.

References False.

Referenced by H264VideoRTPSink::sourceIsCompatibleWithUs().

00052                                                    {
00053   return False; // default implementation
00054 }

Boolean MediaSource::isJPEGVideoSource ( ) const [virtual, inherited]

Reimplemented in JPEGVideoSource.

Definition at line 55 of file MediaSource.cpp.

References False.

Referenced by JPEGVideoRTPSink::sourceIsCompatibleWithUs().

00055                                              {
00056   return False; // default implementation
00057 }

Boolean MediaSource::isAMRAudioSource ( ) const [virtual, inherited]

Reimplemented in AMRAudioSource.

Definition at line 58 of file MediaSource.cpp.

References False.

Referenced by AMRAudioRTPSink::sourceIsCompatibleWithUs(), and AMRAudioFileSink::sourceIsCompatibleWithUs().

00058                                             {
00059   return False; // default implementation
00060 }

void Medium::close	(	UsageEnvironment &	env,
		char const *	mediumName
	)			`[static, inherited]`

Definition at line 76 of file Media.cpp.

References env, MediaLookupTable::ourMedia(), and MediaLookupTable::remove().

Referenced by afterPlaying(), Medium::close(), closeMediaSinks(), OnDemandServerMediaSubsession::closeStreamSource(), WAVAudioFileSource::createNew(), QCELPAudioRTPSource::createNew(), MP3HTTPSource::createNew(), MP3FileSource::createNew(), AMRAudioRTPSource::createNew(), WAVAudioFileServerMediaSubsession::createNewStreamSource(), MPEG1or2DemuxedServerMediaSubsession::createNewStreamSource(), MediaSubsession::deInitiate(), MediaSubsession::initiate(), MPEG1or2ProgramStreamFileDuration(), MPEG1or2Demux::noteElementaryStreamDeletion(), ByteStreamMultiFileSource::onSourceClosure1(), StreamState::reclaim(), RTSPServer::removeServerMediaSession(), OnDemandServerMediaSubsession::sdpLines(), shutdown(), H264VideoRTPSink::stopPlaying(), subsessionAfterPlaying(), ClientTrickPlayState::updateStateOnScaleChange(), AMRDeinterleaver::~AMRDeinterleaver(), ByteStreamMultiFileSource::~ByteStreamMultiFileSource(), DarwinInjector::~DarwinInjector(), FramedFilter::~FramedFilter(), H264VideoRTPSink::~H264VideoRTPSink(), InputESSourceRecord::~InputESSourceRecord(), MPEG1or2Demux::~MPEG1or2Demux(), MPEG1or2FileServerDemux::~MPEG1or2FileServerDemux(), MPEG2TransportFileServerMediaSubsession::~MPEG2TransportFileServerMediaSubsession(), MPEG2TransportStreamFromPESSource::~MPEG2TransportStreamFromPESSource(), ServerMediaSession::~ServerMediaSession(), and ServerMediaSubsession::~ServerMediaSubsession().

00076                                                           {
00077   MediaLookupTable::ourMedia(env)->remove(name);
00078 }

void Medium::close ( Medium * medium ) [static, inherited]

Definition at line 80 of file Media.cpp.

References Medium::close(), Medium::envir(), Medium::name(), and NULL.

00080                                  {
00081   if (medium == NULL) return;
00082
00083   close(medium->envir(), medium->name());
00084 }

UsageEnvironment& Medium::envir ( ) const [inline, inherited]

Definition at line 59 of file Media.hh.

References Medium::fEnviron.

00059 {return fEnviron;}

char const* Medium::name ( ) const [inline, inherited]

Definition at line 61 of file Media.hh.

References Medium::fMediumName.

Referenced by QuickTimeFileSink::addAtom_hdlr2(), Medium::close(), MP3ADUTranscoder::createNew(), MP3FromADUSource::createNew(), ADUFromMP3Source::createNew(), and MP3FileSource::initializeStream().

00061 {return fMediumName;}

Boolean Medium::isSink ( ) const [virtual, inherited]

Reimplemented in MediaSink.

Definition at line 90 of file Media.cpp.

References False.

Referenced by MediaSink::lookupByName().

00090                              {
00091   return False; // default implementation
00092 }

Boolean Medium::isRTCPInstance ( ) const [virtual, inherited]

Reimplemented in RTCPInstance.

Definition at line 94 of file Media.cpp.

References False.

Referenced by RTCPInstance::lookupByName().

00094                                      {
00095   return False; // default implementation
00096 }

Boolean Medium::isRTSPClient ( ) const [virtual, inherited]

Reimplemented in RTSPClient.

Definition at line 98 of file Media.cpp.

References False.

Referenced by RTSPClient::lookupByName().


Public Types
typedef void(	afterGettingFunc )(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds)
typedef void(	onCloseFunc )(void *clientData)
Public Member Functions
virtual	~BasicUDPSource ()
Groupsock *	gs () const
void	getNextFrame (unsigned char to, unsigned maxSize, afterGettingFunc afterGettingFunc, void afterGettingClientData, onCloseFunc onCloseFunc, void *onCloseClientData)
void	stopGettingFrames ()
virtual unsigned	maxFrameSize () const
Boolean	isCurrentlyAwaitingData () const
virtual void	getAttributes () const
virtual char const *	MIMEtype () const
virtual Boolean	isRTPSource () const
virtual Boolean	isMPEG1or2VideoStreamFramer () const
virtual Boolean	isMPEG4VideoStreamFramer () const
virtual Boolean	isH264VideoStreamFramer () const
virtual Boolean	isJPEGVideoSource () const
virtual Boolean	isAMRAudioSource () const
UsageEnvironment &	envir () const
char const *	name () const
virtual Boolean	isSink () const
virtual Boolean	isRTCPInstance () const
virtual Boolean	isRTSPClient () const
virtual Boolean	isRTSPServer () const
virtual Boolean	isMediaSession () const
virtual Boolean	isServerMediaSession () const
virtual Boolean	isDarwinInjector () const
Static Public Member Functions
static BasicUDPSource *	createNew (UsageEnvironment &env, Groupsock *inputGS)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, FramedSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, MediaSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const mediumName, Medium &resultMedium)
static void	handleClosure (void *clientData)
static void	close (UsageEnvironment &env, char const *mediumName)
static void	close (Medium *medium)
Protected Member Functions
TaskToken &	nextTask ()
Static Protected Member Functions
static void	afterGetting (FramedSource *source)
Protected Attributes
unsigned char *	fTo
unsigned	fMaxSize
unsigned	fFrameSize
unsigned	fNumTruncatedBytes
timeval	fPresentationTime
unsigned	fDurationInMicroseconds
Private Member Functions
	BasicUDPSource (UsageEnvironment &env, Groupsock *inputGS)
void	incomingPacketHandler1 ()
virtual void	doGetNextFrame ()
virtual void	doStopGettingFrames ()
Static Private Member Functions
static void	incomingPacketHandler (BasicUDPSource *source, int mask)
Private Attributes
Groupsock *	fInputGS
Boolean	fHaveStartedReading

BasicUDPSource Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Private Member Functions

Static Private Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation
