MultiFramedRTPSource Class Reference

#include <MultiFramedRTPSource.hh>

Inheritance diagram for MultiFramedRTPSource:

[legend]Collaboration diagram for MultiFramedRTPSource:


Public Types
typedef void(	afterGettingFunc )(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds)
typedef void(	onCloseFunc )(void *clientData)
Public Member Functions
Boolean	curPacketMarkerBit () const
unsigned char	rtpPayloadFormat () const
virtual Boolean	hasBeenSynchronizedUsingRTCP ()
Groupsock *	RTPgs () const
u_int32_t	SSRC () const
unsigned	timestampFrequency () const
RTPReceptionStatsDB &	receptionStatsDB () const
u_int32_t	lastReceivedSSRC () const
void	setStreamSocket (int sockNum, unsigned char streamChannelId)
void	setAuxilliaryReadHandler (AuxHandlerFunc handlerFunc, void handlerClientData)
u_int16_t	curPacketRTPSeqNum () const
u_int32_t	curPacketRTPTimestamp () const
void	getNextFrame (unsigned char to, unsigned maxSize, afterGettingFunc afterGettingFunc, void afterGettingClientData, onCloseFunc onCloseFunc, void *onCloseClientData)
void	stopGettingFrames ()
virtual unsigned	maxFrameSize () const
Boolean	isCurrentlyAwaitingData () const
virtual char const *	MIMEtype () const
virtual Boolean	isMPEG1or2VideoStreamFramer () const
virtual Boolean	isMPEG4VideoStreamFramer () const
virtual Boolean	isH264VideoStreamFramer () const
virtual Boolean	isJPEGVideoSource () const
virtual Boolean	isAMRAudioSource () const
UsageEnvironment &	envir () const
char const *	name () const
virtual Boolean	isSink () const
virtual Boolean	isRTCPInstance () const
virtual Boolean	isRTSPClient () const
virtual Boolean	isRTSPServer () const
virtual Boolean	isMediaSession () const
virtual Boolean	isServerMediaSession () const
virtual Boolean	isDarwinInjector () const
Static Public Member Functions
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, RTPSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, FramedSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, MediaSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const mediumName, Medium &resultMedium)
static void	handleClosure (void *clientData)
static void	close (UsageEnvironment &env, char const *mediumName)
static void	close (Medium *medium)
Protected Member Functions
	MultiFramedRTPSource (UsageEnvironment &env, Groupsock RTPgs, unsigned char rtpPayloadFormat, unsigned rtpTimestampFrequency, BufferedPacketFactory packetFactory=NULL)
virtual	~MultiFramedRTPSource ()
virtual Boolean	processSpecialHeader (BufferedPacket *packet, unsigned &resultSpecialHeaderSize)
virtual Boolean	packetIsUsableInJitterCalculation (unsigned char *packet, unsigned packetSize)
virtual void	doStopGettingFrames ()
TaskToken &	nextTask ()
Static Protected Member Functions
static void	afterGetting (FramedSource *source)
Protected Attributes
Boolean	fCurrentPacketBeginsFrame
Boolean	fCurrentPacketCompletesFrame
RTPInterface	fRTPInterface
u_int16_t	fCurPacketRTPSeqNum
u_int32_t	fCurPacketRTPTimestamp
Boolean	fCurPacketMarkerBit
Boolean	fCurPacketHasBeenSynchronizedUsingRTCP
u_int32_t	fLastReceivedSSRC
unsigned char *	fTo
unsigned	fMaxSize
unsigned	fFrameSize
unsigned	fNumTruncatedBytes
timeval	fPresentationTime
unsigned	fDurationInMicroseconds
Private Member Functions
virtual void	doGetNextFrame ()
virtual void	setPacketReorderingThresholdTime (unsigned uSeconds)
void	reset ()
void	doGetNextFrame1 ()
Static Private Member Functions
static void	networkReadHandler (MultiFramedRTPSource *source, int)
Private Attributes
Boolean	fAreDoingNetworkReads
Boolean	fNeedDelivery
Boolean	fPacketLossInFragmentedFrame
unsigned char *	fSavedTo
unsigned	fSavedMaxSize
ReorderingPacketBuffer *	fReorderingBuffer
Friends
void	networkReadHandler (MultiFramedRTPSource *, int)

Detailed Description

Definition at line 32 of file MultiFramedRTPSource.hh.

Member Typedef Documentation

typedef void( FramedSource::afterGettingFunc)(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds) [inherited]

Definition at line 36 of file FramedSource.hh.

typedef void( FramedSource::onCloseFunc)(void *clientData) [inherited]

Definition at line 40 of file FramedSource.hh.

Constructor & Destructor Documentation

MultiFramedRTPSource::MultiFramedRTPSource	(	UsageEnvironment &	env,
		Groupsock *	RTPgs,
		unsigned char	rtpPayloadFormat,
		unsigned	rtpTimestampFrequency,
		BufferedPacketFactory *	packetFactory = `NULL`
	)			`[protected]`

Definition at line 64 of file MultiFramedRTPSource.cpp.

References env, increaseReceiveBufferTo(), reset(), and Socket::socketNum().

00068   : RTPSource(env, RTPgs, rtpPayloadFormat, rtpTimestampFrequency) {
00069   reset();
00070   fReorderingBuffer = new ReorderingPacketBuffer(packetFactory);
00071
00072   // Try to use a big receive buffer for RTP:
00073   increaseReceiveBufferTo(env, RTPgs->socketNum(), 50*1024);
00074 }

MultiFramedRTPSource::~MultiFramedRTPSource ( ) [protected, virtual]

Definition at line 84 of file MultiFramedRTPSource.cpp.

References fReorderingBuffer, RTPSource::fRTPInterface, and RTPInterface::stopNetworkReading().

00084                                             {
00085   fRTPInterface.stopNetworkReading();
00086   delete fReorderingBuffer;
00087 }

Member Function Documentation

Boolean MultiFramedRTPSource::processSpecialHeader	(	BufferedPacket *	packet,
		unsigned &	resultSpecialHeaderSize
	)			`[protected, virtual]`

Reimplemented in RawAMRRTPSource, AC3AudioRTPSource, H261VideoRTPSource, H263plusVideoRTPSource, H264VideoRTPSource, JPEGVideoRTPSource, MPEG1or2AudioRTPSource, MPEG1or2VideoRTPSource, MPEG4ESVideoRTPSource, MPEG4GenericRTPSource, MPEG4LATMAudioRTPSource, QuickTimeGenericRTPSource, SimpleRTPSource, and RawQCELPRTPSource.

Definition at line 90 of file MultiFramedRTPSource.cpp.

References True.

Referenced by doGetNextFrame1().

00091                                                           {
00092   // Default implementation: Assume no special header:
00093   resultSpecialHeaderSize = 0;
00094   return True;
00095 }

Boolean MultiFramedRTPSource::packetIsUsableInJitterCalculation	(	unsigned char *	packet,
		unsigned	packetSize
	)			`[protected, virtual]`

Reimplemented in MPEG1or2VideoRTPSource.

Definition at line 98 of file MultiFramedRTPSource.cpp.

References True.

Referenced by networkReadHandler().

00099                                                              {
00100   // Default implementation:
00101   return True;
00102 }

void MultiFramedRTPSource::doStopGettingFrames ( ) [protected, virtual]

Reimplemented from FramedSource.

Definition at line 104 of file MultiFramedRTPSource.cpp.

References fReorderingBuffer, RTPSource::fRTPInterface, reset(), ReorderingPacketBuffer::reset(), and RTPInterface::stopNetworkReading().

00104                                                {
00105   fRTPInterface.stopNetworkReading();
00106   fReorderingBuffer->reset();
00107   reset();
00108 }

void MultiFramedRTPSource::doGetNextFrame ( ) [private, virtual]

Implements FramedSource.

Definition at line 110 of file MultiFramedRTPSource.cpp.

References doGetNextFrame1(), fAreDoingNetworkReads, FramedSource::fFrameSize, FramedSource::fMaxSize, fNeedDelivery, RTPSource::fRTPInterface, fSavedMaxSize, fSavedTo, FramedSource::fTo, networkReadHandler(), RTPInterface::startNetworkReading(), and True.

00110                                           {
00111   if (!fAreDoingNetworkReads) {
00112     // Turn on background read handling of incoming packets:
00113     fAreDoingNetworkReads = True;
00114     TaskScheduler::BackgroundHandlerProc* handler
00115       = (TaskScheduler::BackgroundHandlerProc*)&networkReadHandler;
00116     fRTPInterface.startNetworkReading(handler);
00117   }
00118
00119   fSavedTo = fTo;
00120   fSavedMaxSize = fMaxSize;
00121   fFrameSize = 0; // for now
00122   fNeedDelivery = True;
00123   doGetNextFrame1();
00124 }

void MultiFramedRTPSource::setPacketReorderingThresholdTime ( unsigned uSeconds ) [private, virtual]

Implements RTPSource.

Definition at line 211 of file MultiFramedRTPSource.cpp.

References fReorderingBuffer, and ReorderingPacketBuffer::setThresholdTime().

Referenced by networkReadHandler().

00211                                                     {
00212   fReorderingBuffer->setThresholdTime(uSeconds);
00213 }

void MultiFramedRTPSource::reset ( ) [private]

Definition at line 76 of file MultiFramedRTPSource.cpp.

References False, fAreDoingNetworkReads, fCurrentPacketBeginsFrame, fCurrentPacketCompletesFrame, fNeedDelivery, fPacketLossInFragmentedFrame, and True.

Referenced by doStopGettingFrames().

00076                                  {
00077   fCurrentPacketBeginsFrame = True; // by default
00078   fCurrentPacketCompletesFrame = True; // by default
00079   fAreDoingNetworkReads = False;
00080   fNeedDelivery = False;
00081   fPacketLossInFragmentedFrame = False;
00082 }

void MultiFramedRTPSource::doGetNextFrame1 ( ) [private]

Definition at line 126 of file MultiFramedRTPSource.cpp.

References FramedSource::afterGetting(), Medium::envir(), False, RTPSource::fCurPacketHasBeenSynchronizedUsingRTCP, RTPSource::fCurPacketMarkerBit, RTPSource::fCurPacketRTPSeqNum, RTPSource::fCurPacketRTPTimestamp, fCurrentPacketBeginsFrame, fCurrentPacketCompletesFrame, FramedSource::fFrameSize, FramedSource::fMaxSize, fNeedDelivery, FramedSource::fNumTruncatedBytes, fPacketLossInFragmentedFrame, FramedSource::fPresentationTime, frameSize, fReorderingBuffer, fSavedMaxSize, fSavedTo, FramedSource::fTo, ReorderingPacketBuffer::getNextCompletedPacket(), BufferedPacket::hasUsableData(), ReorderingPacketBuffer::isEmpty(), Medium::nextTask(), NULL, processSpecialHeader(), ReorderingPacketBuffer::releaseUsedPacket(), TaskScheduler::scheduleDelayedTask(), BufferedPacket::skip(), UsageEnvironment::taskScheduler(), True, BufferedPacket::use(), and BufferedPacket::useCount().

Referenced by doGetNextFrame(), and networkReadHandler().

00126                                            {
00127   while (fNeedDelivery) {
00128     // If we already have packet data available, then deliver it now.
00129     Boolean packetLossPrecededThis;
00130     BufferedPacket* nextPacket
00131       = fReorderingBuffer->getNextCompletedPacket(packetLossPrecededThis);
00132     if (nextPacket == NULL) break;
00133
00134     fNeedDelivery = False;
00135
00136     if (nextPacket->useCount() == 0) {
00137       // Before using the packet, check whether it has a special header
00138       // that needs to be processed:
00139       unsigned specialHeaderSize;
00140       if (!processSpecialHeader(nextPacket, specialHeaderSize)) {
00141         // Something's wrong with the header; reject the packet:
00142         fReorderingBuffer->releaseUsedPacket(nextPacket);
00143         fNeedDelivery = True;
00144         break;
00145       }
00146       nextPacket->skip(specialHeaderSize);
00147     }
00148
00149     // Check whether we're part of a multi-packet frame, and whether
00150     // there was packet loss that would render this packet unusable:
00151     if (fCurrentPacketBeginsFrame) {
00152       if (packetLossPrecededThis || fPacketLossInFragmentedFrame) {
00153         // We didn't get all of the previous frame.
00154         // Forget any data that we used from it:
00155         fTo = fSavedTo; fMaxSize = fSavedMaxSize;
00156         fFrameSize = 0;
00157       }
00158       fPacketLossInFragmentedFrame = False;
00159     } else if (packetLossPrecededThis) {
00160       // We're in a multi-packet frame, with preceding packet loss
00161       fPacketLossInFragmentedFrame = True;
00162     }
00163     if (fPacketLossInFragmentedFrame) {
00164       // This packet is unusable; reject it:
00165       fReorderingBuffer->releaseUsedPacket(nextPacket);
00166       fNeedDelivery = True;
00167       break;
00168     }
00169
00170     // The packet is usable. Deliver all or part of it to our caller:
00171     unsigned frameSize;
00172     nextPacket->use(fTo, fMaxSize, frameSize, fNumTruncatedBytes,
00173                     fCurPacketRTPSeqNum, fCurPacketRTPTimestamp,
00174                     fPresentationTime, fCurPacketHasBeenSynchronizedUsingRTCP,
00175                     fCurPacketMarkerBit);
00176     fFrameSize += frameSize;
00177
00178     if (!nextPacket->hasUsableData()) {
00179       // We're completely done with this packet now
00180       fReorderingBuffer->releaseUsedPacket(nextPacket);
00181     }
00182
00183     if (fCurrentPacketCompletesFrame || fNumTruncatedBytes > 0) {
00184       // We have all the data that the client wants.
00185       if (fNumTruncatedBytes > 0) {
00186         envir() << "MultiFramedRTPSource::doGetNextFrame1(): The total received frame size exceeds the client's buffer size ("
00187                 << fSavedMaxSize << ").  "
00188                 << fNumTruncatedBytes << " bytes of trailing data will be dropped!\n";
00189       }
00190       // Call our own 'after getting' function, so that the downstream object can consume the data:
00191       if (fReorderingBuffer->isEmpty()) {
00192         // Common case optimization: There are no more queued incoming packets, so this code will not get
00193         // executed again without having first returned to the event loop.  Call our 'after getting' function
00194         // directly, because there's no risk of a long chain of recursion (and thus stack overflow):
00195         afterGetting(this);
00196       } else {
00197         // Special case: Call our 'after getting' function via the event loop.
00198         nextTask() = envir().taskScheduler().scheduleDelayedTask(0,
00199                                                                  (TaskFunc*)FramedSource::afterGetting, this);
00200       }
00201     } else {
00202       // This packet contained fragmented data, and does not complete
00203       // the data that the client wants.  Keep getting data:
00204       fTo += frameSize; fMaxSize -= frameSize;
00205       fNeedDelivery = True;
00206     }
00207   }
00208 }

void MultiFramedRTPSource::networkReadHandler	(	MultiFramedRTPSource *	source,
		int
	)			`[static, private]`

Definition at line 217 of file MultiFramedRTPSource.cpp.

References ADVANCE, BufferedPacket::assignMiscParams(), BufferedPacket::data(), BufferedPacket::dataSize(), doGetNextFrame1(), False, BufferedPacket::fillInData(), RTPSource::fLastReceivedSSRC, ReorderingPacketBuffer::freePacket(), fReorderingBuffer, RTPSource::fRTPInterface, ReorderingPacketBuffer::getFreePacket(), RTPReceptionStatsDB::noteIncomingPacket(), NULL, our_random(), packetIsUsableInJitterCalculation(), RTPSource::receptionStatsDB(), BufferedPacket::removePadding(), RTPSource::rtpPayloadFormat(), setPacketReorderingThresholdTime(), ReorderingPacketBuffer::storePacket(), RTPSource::timestampFrequency(), and True.

Referenced by doGetNextFrame().

00218                                                             {
00219   // Get a free BufferedPacket descriptor to hold the new network packet:
00220   BufferedPacket* bPacket
00221     = source->fReorderingBuffer->getFreePacket(source);
00222
00223   // Read the network packet, and perform sanity checks on the RTP header:
00224   Boolean readSuccess = False;
00225   do {
00226     if (!bPacket->fillInData(source->fRTPInterface)) break;
00227 #ifdef TEST_LOSS
00228     source->setPacketReorderingThresholdTime(0);
00229        // don't wait for 'lost' packets to arrive out-of-order later
00230     if ((our_random()%10) == 0) break; // simulate 10% packet loss
00231 #endif
00232
00233     // Check for the 12-byte RTP header:
00234     if (bPacket->dataSize() < 12) break;
00235     unsigned rtpHdr = ntohl(*(unsigned*)(bPacket->data())); ADVANCE(4);
00236     Boolean rtpMarkerBit = (rtpHdr&0x00800000) >> 23;
00237     unsigned rtpTimestamp = ntohl(*(unsigned*)(bPacket->data()));ADVANCE(4);
00238     unsigned rtpSSRC = ntohl(*(unsigned*)(bPacket->data())); ADVANCE(4);
00239
00240     // Check the RTP version number (it should be 2):
00241     if ((rtpHdr&0xC0000000) != 0x80000000) break;
00242
00243     // Skip over any CSRC identifiers in the header:
00244     unsigned cc = (rtpHdr>>24)&0xF;
00245     if (bPacket->dataSize() < cc) break;
00246     ADVANCE(cc*4);
00247
00248     // Check for (& ignore) any RTP header extension
00249     if (rtpHdr&0x10000000) {
00250       if (bPacket->dataSize() < 4) break;
00251       unsigned extHdr = ntohl(*(unsigned*)(bPacket->data())); ADVANCE(4);
00252       unsigned remExtSize = 4*(extHdr&0xFFFF);
00253       if (bPacket->dataSize() < remExtSize) break;
00254       ADVANCE(remExtSize);
00255     }
00256
00257     // Discard any padding bytes:
00258     if (rtpHdr&0x20000000) {
00259       if (bPacket->dataSize() == 0) break;
00260       unsigned numPaddingBytes
00261         = (unsigned)(bPacket->data())[bPacket->dataSize()-1];
00262       if (bPacket->dataSize() < numPaddingBytes) break;
00263       bPacket->removePadding(numPaddingBytes);
00264     }
00265     // Check the Payload Type.
00266     if ((unsigned char)((rtpHdr&0x007F0000)>>16)
00267         != source->rtpPayloadFormat()) {
00268       break;
00269     }
00270
00271     // The rest of the packet is the usable data.  Record and save it:
00272     source->fLastReceivedSSRC = rtpSSRC;
00273     unsigned short rtpSeqNo = (unsigned short)(rtpHdr&0xFFFF);
00274     Boolean usableInJitterCalculation
00275       = source->packetIsUsableInJitterCalculation((bPacket->data()),
00276                                                   bPacket->dataSize());
00277     struct timeval presentationTime; // computed by:
00278     Boolean hasBeenSyncedUsingRTCP; // computed by:
00279     source->receptionStatsDB()
00280       .noteIncomingPacket(rtpSSRC, rtpSeqNo, rtpTimestamp,
00281                           source->timestampFrequency(),
00282                           usableInJitterCalculation, presentationTime,
00283                           hasBeenSyncedUsingRTCP, bPacket->dataSize());
00284
00285     // Fill in the rest of the packet descriptor, and store it:
00286     struct timeval timeNow;
00287     gettimeofday(&timeNow, NULL);
00288     bPacket->assignMiscParams(rtpSeqNo, rtpTimestamp, presentationTime,
00289                               hasBeenSyncedUsingRTCP, rtpMarkerBit,
00290                               timeNow);
00291     if (!source->fReorderingBuffer->storePacket(bPacket)) break;
00292
00293     readSuccess = True;
00294   } while (0);
00295   if (!readSuccess) source->fReorderingBuffer->freePacket(bPacket);
00296
00297   source->doGetNextFrame1();
00298   // If we didn't get proper data this time, we'll get another chance
00299 }

Boolean RTPSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		RTPSource *&	resultSource
	)			`[static, inherited]`

Definition at line 26 of file RTPSource.cpp.

References env, False, MediaSource::isRTPSource(), MediaSource::lookupByName(), NULL, and True.

00028                                                           {
00029   resultSource = NULL; // unless we succeed
00030
00031   MediaSource* source;
00032   if (!MediaSource::lookupByName(env, sourceName, source)) return False;
00033
00034   if (!source->isRTPSource()) {
00035     env.setResultMsg(sourceName, " is not a RTP source");
00036     return False;
00037   }
00038
00039   resultSource = (RTPSource*)source;
00040   return True;
00041 }

Boolean FramedSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		FramedSource *&	resultSource
	)			`[static, inherited]`

Definition at line 41 of file FramedSource.cpp.

References env, False, MediaSource::isFramedSource(), MediaSource::lookupByName(), NULL, and True.

Referenced by MP3ADUinterleaverBase::getInputSource().

00042                                                                 {
00043   resultSource = NULL; // unless we succeed
00044
00045   MediaSource* source;
00046   if (!MediaSource::lookupByName(env, sourceName, source)) return False;
00047
00048   if (!source->isFramedSource()) {
00049     env.setResultMsg(sourceName, " is not a framed source");
00050     return False;
00051   }
00052
00053   resultSource = (FramedSource*)source;
00054   return True;
00055 }

Boolean MediaSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		MediaSource *&	resultSource
	)			`[static, inherited]`

Definition at line 62 of file MediaSource.cpp.

References env, False, Medium::isSource(), Medium::lookupByName(), NULL, and True.

Referenced by RTPSource::lookupByName(), and FramedSource::lookupByName().

00064                                                               {
00065   resultSource = NULL; // unless we succeed
00066
00067   Medium* medium;
00068   if (!Medium::lookupByName(env, sourceName, medium)) return False;
00069
00070   if (!medium->isSource()) {
00071     env.setResultMsg(sourceName, " is not a media source");
00072     return False;
00073   }
00074
00075   resultSource = (MediaSource*)medium;
00076   return True;
00077 }

Boolean Medium::lookupByName	(	UsageEnvironment &	env,
		char const *	mediumName,
		Medium *&	resultMedium
	)			`[static, inherited]`

Definition at line 65 of file Media.cpp.

References env, False, MediaLookupTable::lookup(), NULL, MediaLookupTable::ourMedia(), UsageEnvironment::setResultMsg(), and True.

Referenced by ServerMediaSession::lookupByName(), RTSPServer::lookupByName(), RTSPClient::lookupByName(), RTCPInstance::lookupByName(), MediaSource::lookupByName(), MediaSink::lookupByName(), MediaSession::lookupByName(), and DarwinInjector::lookupByName().

00066                                                          {
00067   resultMedium = MediaLookupTable::ourMedia(env)->lookup(mediumName);
00068   if (resultMedium == NULL) {
00069     env.setResultMsg("Medium ", mediumName, " does not exist");
00070     return False;
00071   }
00072
00073   return True;
00074 }

Boolean RTPSource::curPacketMarkerBit ( ) const [inline, inherited]

Definition at line 38 of file RTPSource.hh.

References RTPSource::fCurPacketMarkerBit.

Referenced by SubsessionIOState::useFrameForHinting().

00038 { return fCurPacketMarkerBit; }

unsigned char RTPSource::rtpPayloadFormat ( ) const [inline, inherited]

Definition at line 40 of file RTPSource.hh.

References RTPSource::fRTPPayloadFormat.

Referenced by QuickTimeFileSink::addAtom_hdlr2(), networkReadHandler(), and SubsessionIOState::useFrameForHinting().

00040 { return fRTPPayloadFormat; }

Boolean RTPSource::hasBeenSynchronizedUsingRTCP ( ) [virtual, inherited]

Reimplemented in RawAMRRTPSource, and RawQCELPRTPSource.

Definition at line 43 of file RTPSource.cpp.

References RTPSource::fCurPacketHasBeenSynchronizedUsingRTCP.

Referenced by checkForPacketArrival(), RawQCELPRTPSource::processSpecialHeader(), RawAMRRTPSource::processSpecialHeader(), SubsessionIOState::syncOK(), and SubsessionIOState::useFrame().

00043                                                 {
00044   return fCurPacketHasBeenSynchronizedUsingRTCP;
00045 }

Groupsock* RTPSource::RTPgs ( ) const [inline, inherited]

u_int32_t RTPSource::SSRC ( ) const [inline, inherited]

Definition at line 49 of file RTPSource.hh.

References RTPSource::fSSRC.

Referenced by RTCPInstance::addBYE(), RTCPInstance::addRR(), and RTCPInstance::addSDES().

00049 { return fSSRC; }

unsigned RTPSource::timestampFrequency ( ) const [inline, inherited]

Definition at line 53 of file RTPSource.hh.

References RTPSource::fTimestampFrequency.

Referenced by QuickTimeFileSink::addAtom_hdlr2(), networkReadHandler(), and RTPReceptionStats::noteIncomingPacket().

00053 {return fTimestampFrequency;}

RTPReceptionStatsDB& RTPSource::receptionStatsDB ( ) const [inline, inherited]

Definition at line 55 of file RTPSource.hh.

References RTPSource::fReceptionStatsDB.

Referenced by checkForPacketArrival(), checkInterPacketGaps(), RTCPInstance::enqueueCommonReportSuffix(), RTCPInstance::incomingReportHandler1(), networkReadHandler(), printQOSData(), qosMeasurementRecord::qosMeasurementRecord(), and RTCPInstance::removeSSRC().

00055                                                 {
00056     return *fReceptionStatsDB;
00057   }

u_int32_t RTPSource::lastReceivedSSRC ( ) const [inline, inherited]

Definition at line 59 of file RTPSource.hh.

References RTPSource::fLastReceivedSSRC.

00059 { return fLastReceivedSSRC; }

void RTPSource::setStreamSocket	(	int	sockNum,
		unsigned char	streamChannelId
	)			`[inline, inherited]`

Definition at line 62 of file RTPSource.hh.

References RTPSource::fRTPInterface, and RTPInterface::setStreamSocket().

Referenced by RTSPClient::setupMediaSubsession().

00062                                                                    {
00063     // hack to allow sending RTP over TCP (RFC 2236, section 10.12)
00064     fRTPInterface.setStreamSocket(sockNum, streamChannelId);
00065   }

void RTPSource::setAuxilliaryReadHandler	(	AuxHandlerFunc *	handlerFunc,
		void *	handlerClientData
	)			`[inline, inherited]`

Definition at line 67 of file RTPSource.hh.

References RTPSource::fRTPInterface, and RTPInterface::setAuxilliaryReadHandler().

00068                                                          {
00069     fRTPInterface.setAuxilliaryReadHandler(handlerFunc,
00070                                            handlerClientData);
00071   }

u_int16_t RTPSource::curPacketRTPSeqNum ( ) const [inline, inherited]

Definition at line 76 of file RTPSource.hh.

References RTPSource::fCurPacketRTPSeqNum.

Referenced by SubsessionIOState::afterGettingFrame(), AVISubsessionIOState::afterGettingFrame(), QCELPDeinterleaver::afterGettingFrame1(), and AMRDeinterleavingBuffer::deliverIncomingFrame().

00076 { return fCurPacketRTPSeqNum; }

u_int32_t RTPSource::curPacketRTPTimestamp ( ) const [inline, inherited]

Definition at line 77 of file RTPSource.hh.

References RTPSource::fCurPacketRTPTimestamp.

Referenced by MediaSubsession::getNormalPlayTime().

00077 { return fCurPacketRTPTimestamp; }

void FramedSource::getNextFrame	(	unsigned char *	to,
		unsigned	maxSize,
		afterGettingFunc *	afterGettingFunc,
		void *	afterGettingClientData,
		onCloseFunc *	onCloseFunc,
		void *	onCloseClientData
	)			`[inherited]`

Definition at line 57 of file FramedSource.cpp.

References FramedSource::doGetNextFrame(), Medium::envir(), FramedSource::fAfterGettingClientData, FramedSource::fAfterGettingFunc, FramedSource::fDurationInMicroseconds, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fMaxSize, FramedSource::fNumTruncatedBytes, FramedSource::fOnCloseClientData, FramedSource::fOnCloseFunc, FramedSource::fTo, and True.

Referenced by MPEG2TransportStreamFramer::afterGettingFrame1(), InputESSourceRecord::askForNewData(), MPEG2TransportStreamFromPESSource::awaitNewBuffer(), QuickTimeFileSink::continuePlaying(),

MultiFramedRTPSource Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Private Member Functions

Static Private Member Functions

Private Attributes

Friends

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation
